Notifier AFP-400 - Mounting an Optional AVPS-24 Power Supply

 ,QVWDOODWLRQ Mounting an Optional AVPS-24 Power Supply
2-10 AFP-300/AFP-400 Installation PN 50253:C1 05/22/97
0RXQWLQJDQ2SWLRQDO$9363RZHU6XSSO\
2YHUYLHZ
You can mount an AVPS-24 into a CAB-X3 series cabinet (on a CHS-4 or CHS-4L
chassis) or in the upper right corner of a CAB-400AA. A CRM-4, a ICM-4, a DCM-4,
or a VCM-4 can mount above the AVPS-24 as long as you do not use an expander
module (CRE-4, ICE-4, or VCE-4).
,QVWDOODWLRQ
To mount an AVPS-24, refer to Figure 2-12 and follow these steps:
Figure 2-12 shows how to mount an AVPS-24 onto a CHS-4L chassis:
)LJXUH  0RXQWLQJ DQ $936 3RZHU 6XSSO\
Step Action
1 Place the AVPS-24 module onto the screw mounts on the CHS-4 or CHS-4L
chassis as shown in Figure 2-12.
2 Install the two mounting nuts.
3 Tighten the mounting nuts until the module is secure.
1XW DQG ORFNZDVKHU  SODFHV
&+6&+6/
$936
