Voice Alarm Equipment  6\VWHP 2YHUYLHZ
AFP-300/AFP-400 Installation PN 50253:C1 05/22/97 1-19
9RLFH$ODUP(TXLSPHQ W
2YHUYLHZ
Voice Alarm equipment provides a manual or automatic supervised paging system for
transmitting voice messages (information, instructions, directions) on a selective or all
call basis. For more details, refer to Section 4, Voice Alarm System.
$XGLR 0HVVD
J
H*HQHUDWRU$0*
The heart of a voice evacuation system, the Audio Message Generator (AMG-1)
provides a variety of tones, including a slow whoop, yelp, yeow, siren, hi/lo, or steady
tone. A built-in microphone allows for paging through speaker circuits. Optionally,
you can install up to four digitally-recorded voice messages into the AMG-1 from the
following:
• two factory prerecorded VROM voice messages;
• two user-defined messages in the AMG-1;
• two user-defined messages (up to 24 seconds long) into an AMG-1 with optional
VRAM-1 memory chips installed (one per VRAM).
You can create both user-defined messages through the AMG-1 built-in microphone, or
download user-defined messages from a standard audio cassette recorder.
$XGLR7RQH*HQHUDW RU$7*
The Audio Tone Generator (ATG-2) is similar to the AMG-1, but provides tones and
microphone only (no message). It can provide two simultaneous tones for dual-channel
applications.
)LUH)L
J
KWHUV7HO H
S
KRQH))7))76
The FFT-7 (Fire Fighters Telephone) provides the Voice Alarm System with fire
fighter's telephone capability. With the FFT-7 or FFT-7S, up to seven telephones can
hold a simultaneous conversation.
9RLFH&RQWURO0RGXO H9&0
The Voice Control Module-4 provides the system with up to four Style Y or Style Z
speaker circuits. Moving a jumper on the VCM-4 configures the module for driving
FFT-7 (Fire Fighter Telephone) circuits. When configured for telephone circuits, the
VCM-4 accepts its signal directly from an FFT-7/FFT-7S. Add an optional VCE-4
Voice Control Expander to the back of the VCM-4 to provide telephone or speaker
circuits 5-8.
'XDO&KDQQHO0RGXOH'&0
The DCM-4 Dual Channel Module provides the system with the capability to select one
of two types of audio sources for switching to a specified speaker circuit. The DCM-4
provides up to four circuits.
