Notifier AFP-400 Installation Manual

Annunciator Selection Groups $SSHQGL[ $ $QQXQFLDWRUV
AFP-300/AFP-400 Installation PN 50253:C1 05/22/97 A-3
$&6$QQXQFLDWRU6HOHFWLRQ*URXS
$&6 3RLQW 3RLQW 7\SH 5HG /(' <HOORZ /(' 6ZL WFK )XQFWLRQ &RPPHQWV
1XPEHU ,QGLFDWHV ,QGLFDWHV
1 Input System Alarm System Trouble Acknowledge
2 Output Not Used Signal Silenced Signal Silence
3 Output Not Used Program Mode System Reset
4 Output Not Used Supervisory Drill
5 Output NAC #1 Active NAC Trouble Control NAC #1
6 Input Not Used PA/Maint Alert Not Used
7 Input Not Used Low Battery Not Used
8 Input Not Used AC Fail Not Used
9 Input Zone 1 Active Zone 1 Trouble Not Used
10 Input Zone 2 Active Zone 2 Trouble Not Used
11 Input Zone 3 Active Zone 3 Trouble Not Used
12 Input Zone 4 Active Zone 4 Trouble Not Used
13 Input Zone 5 Active Zone 5 Trouble Not Used
14 Input Zone 6 Active Zone 6 Trouble Not Used
15 Input Zone 7 Active Zone 7 Trouble Not Used
16 Input Zone 8 Active Zone 8 Trouble Not Used
17 Input Zone 9 Active Zone 9 Trouble Not Used
18 Input Zone 10 Active Zone 10 Trouble Not Used
19 Input Zone 11 Active Zone 11 Trouble Not Used
20 Input Zone 12 Active Zone 12 Trouble Not Used
21 Input Zone 13 Active Zone 13 Trouble Not Used
22 Input Zone 14 Active Zone 14 Trouble Not Used
23 Input Zone 15 Active Zone 15 Trouble Not Used
24 Input Zone 16 Active Zone 16 Trouble Not Used
25 Input Zone 17 Active Zone 17 Trouble Not Used
26 Input Zone 18 Active Zone 18 Trouble Not Used
27 Input Zone 19 Active Zone 19 Trouble Not Used
28 Input Zone 20 Active Zone 20 Trouble Not Used
29 Input Zone 21 Active Zone 21 Trouble Not Used
30 Input Zone 22 Active Zone 22 Trouble Not Used
31 Input Zone 23 Active Zone 23 Trouble Not Used
32 Input Zone 24 Active Zone 24 Trouble Not Used
33 Input Zone 25 Active Zone 25 Trouble Not Used
34 Input Zone 26 Active Zone 26 Trouble Not Used
35 Input Zone 27 Active Zone 27 Trouble Not Used
36 Input Zone 28 Active Zone 28 Trouble Not Used
37 Input Zone 29 Active Zone 29 Trouble Not Used
38 Input Zone 30 Active Zone 30 Trouble Not Used
39 Input Zone 31 Active Zone 31 Trouble Not Used
40 Input Zone 32 Active Zone 32 Trouble Not Used
41 Input Zone 33 Active Zone 33 Trouble Not Used
42 Input Zone 34 Active Zone 34 Trouble Not Used
43 Input Zone 35 Active Zone 35 Trouble Not Used
44 Input Zone 36 Active Zone 36 Trouble Not Used
45 Input Zone 37 Active Zone 37 Trouble Not Used
46 Input Zone 38 Active Zone 38 Trouble Not Used
47 Input Zone 39 Active Zone 39 Trouble Not Used
48 Input Zone 40 Active Zone 40 Trouble Not Used
49 Input Zone 41 Active Zone 41 Trouble Not Used
50 Input Zone 42 Active Zone 42 Trouble Not Used
51 Input Zone 43 Active Zone 43 Trouble Not Used
52 Input Zone 44 Active Zone 44 Trouble Not Used
53 Input Zone 45 Active Zone 45 Trouble Not Used
54 Input Zone 46 Active Zone 46 Trouble Not Used
55 Input Zone 47 Active Zone 47 Trouble Not Used
56 Input Zone 48 Active Zone 48 Trouble Not Used
57 Input Zone 49 Active Zone 49 Trouble Not Used
58 Input Zone 50 Active Zone 50 Trouble Not Used
59 Input Zone 51 Active Zone 51 Trouble Not Used
60 Input Zone 52 Active Zone 52 Trouble Not Used
61 Input Zone 53 Active Zone 53 Trouble Not Used
62 Input Zone 54 Active Zone 54 Trouble Not Used
63 Input Zone 55 Active Zone 55 Trouble Not Used
64 Input Zone 56 Active Zone 56 Trouble Not Used
7DEOH $ $&6 $QQXQFLDWRU 6HOHFWLRQ *URXS 
