Annunciator Selection Groups $SSHQGL[ $ $QQXQFLDWRUV
AFP-300/AFP-400 Installation PN 50253:C1 05/22/97 A-11
$&6$QQXQFLDWRU6HOHFWLRQ*URXS
$&6 3RLQW 3RLQW 5HG /(' <HOORZ /(' 6ZLWFK &RPPHQWV
1XPEHU 7\SH ,QGLFDWHV ,QGLFDWHV )XQFWLRQ
1 Output Module P1.1 Active Module P1.1 Trouble Controls Module P1.1
2 Output Module P1.2 Active Module P1.2 Trouble Controls Module P1.2
3 Output Module P1.3 Active Module P1.3 Trouble Controls Module P1.3
4 Output Module P1.4 Active Module P1.4 Trouble Controls Module P1.4
5 Output Module P1.5 Active Module P1.5 Trouble Controls Module P1.5
6 Output Module P1.6 Active Module P1.6 Trouble Controls Module P1.6
7 Output Module P1.7 Active Module P1.7 Trouble Controls Module P1.7
8 Output Module P1.8 Active Module P1.8 Trouble Controls Module P1.8
9 Output Module P2.1 Active Module P2.1 Trouble Controls Module P2.1
10 Output Module P2.2 Active Module P2.2 Trouble Controls Module P2.2
11 Output Module P2.3 Active Module P2.3 Trouble Controls Module P2.3
12 Output Module P2.4 Active Module P2.4 Trouble Controls Module P2.4
13 Output Module P2.5 Active Module P2.5 Trouble Controls Module P2.5
14 Output Module P2.6 Active Module P2.6 Trouble Controls Module P2.6
15 Output Module P2.7 Active Module P2.7 Trouble Controls Module P2.7
16 Output Module P2.8 Active Module P2.8 Trouble Controls Module P2.8
17 Output Module P3.1 Active Module P3.1 Trouble Controls Module P3.1
18 Output Module P3.2 Active Module P3.2 Trouble Controls Module P3.2
19 Output Module P3.3 Active Module P3.3 Trouble Controls Module P3.3
20 Output Module P3.4 Active Module P3.4 Trouble Controls Module P3.4
21 Output Module P3.5 Active Module P3.5 Trouble Controls Module P3.5
22 Output Module P3.6 Active Module P3.6 Trouble Controls Module P3.6
23 Output Module P3.7 Active Module P3.7 Trouble Controls Module P3.7
24 Output Module P3.8 Active Module P3.8 Trouble Controls Module P3.8
25 Output Module P4.1 Active Module P4.1 Trouble Controls Module P4.1
26 Output Module P4.2 Active Module P4.2 Trouble Controls Module P4.2
27 Output Module P4.3 Active Module P4.3 Trouble Controls Module P4.3
28 Output Module P4.4 Active Module P4.4 Trouble Controls Module P4.4
29 Output Module P4.5 Active Module P4.5 Trouble Controls Module P4.5
30 Output Module P4.6 Active Module P4.6 Trouble Controls Module P4.6
31 Output Module P4.7 Active Module P4.7 Trouble Controls Module P4.7
32 Output Module P4.8 Active Module P4.8 Trouble Controls Module P4.8
33 Output Module P5.1 Active Module P5.1 Trouble Controls Module P5.1
34 Output Module P5.2 Active Module P5.2 Trouble Controls Module P5.2
35 Output Module P5.3 Active Module P5.3 Trouble Controls Module P5.3
36 Output Module P5.4 Active Module P5.4 Trouble Controls Module P5.4
37 Output Module P5.5 Active Module P5.5 Trouble Controls Module P5.5
38 Output Module P5.6 Active Module P5.6 Trouble Controls Module P5.6
39 Output Module P5.7 Active Module P5.7 Trouble Controls Module P5.7
40 Output Module P5.8 Active Module P5.8 Trouble Controls Module P5.8
41 Output Module P6.1 Active Module P6.1 Trouble Controls Module P6.1
42 Output Module P6.2 Active Module P6.2 Trouble Controls Module P6.2
43 Output Module P6.3 Active Module P6.3 Trouble Controls Module P6.3
44 Output Module P6.4 Active Module P6.4 Trouble Controls Module P6.4
45 Output Module P6.5 Active Module P6.5 Trouble Controls Module P6.5
46 Output Module P6.6 Active Module P6.6 Trouble Controls Module P6.6
47 Output Module P6.7 Active Module P6.7 Trouble Controls Module P6.7
48 Output Module P6.8 Active Module P6.8 Trouble Controls Module P6.8
49 Output Module P7.1 Active Module P7.1 Trouble Controls Module P7.1
50 Output Module P7.2 Active Module P7.2 Trouble Controls Module P7.2
51 Output Module P7.3 Active Module P7.3 Trouble Controls Module P7.3
52 Output Module P7.4 Active Module P7.4 Trouble Controls Module P7.4
53 Output Module P7.5 Active Module P7.5 Trouble Controls Module P7.5
54 Output Module P7.6 Active Module P7.6 Trouble Controls Module P7.6
55 Output Module P7.7 Active Module P7.7 Trouble Controls Module P7.7
56 Output Module P7.8 Active Module P7.8 Trouble Controls Module P7.8
57 Output Module P8.1 Active Module P8.1 Trouble Controls Module P8.1
58 Output Module P8.2 Active Module P8.2 Trouble Controls Module P8.2
59 Output Module P8.3 Active Module P8.3 Trouble Controls Module P8.3
60 Output Module P8.4 Active Module P8.4 Trouble Controls Module P8.4
61 Output Module P8.5 Active Module P8.5 Trouble Controls Module P8.5
62 Output Module P8.6 Active Module P8.6 Trouble Controls Module P8.6
63 Output Module P8.7 Active Module P8.7 Trouble Controls Module P8.7
64 Output Module P8.8 Active Module P8.8 Trouble Controls Module P8.8
7DEOH $ $&6 $QQXQFLDWRU 6HOHFWLRQ *URXS 
