Section Four
Fire Alarms
The following example illustrates the system format used to display fire alarm conditions:
ALARM:@SMOKE(PHOTO)@@@COMPUTER@ROOM
FOURTEENTH@FLOOR@@@@@@@04:32P@03/01/00@124
SLC Loop Number
in the range 1-9,
with 0= SLC 10.
Device Address
in the range 01-99.
Device Status
Software Zone Label
of the first software zone
that the device was mapped
to during programming.
Device Type (relates to
Software Type ID)
Detectors:
FIXED PHOT D
FIXED THER D
HEAT(ANALOG)
ION DUCT DET
SMOKE (ION)
SMOKE ION HP
SMOKE ION LP
SMOKE(COMBO)
SMOKE(PHOTO)
Modules:
MON NORM CLD
MON PULL STA
MONITOR
PULL STATION
SMOKE (CONV)
WATER FLOW
NOTE
The piezo sounder will pulse for fire alarm conditions.
Time and Date
Hour:Minute Month/Day/Year
Custom Device Label
that was entered during
programming.
