Notifier AM2020 User Manual

2-24 Operating 15088: J 10/22/99
Section 5.1 Trouble ................. with SLC Loop Devices
The following example illustrates the format used to display device trouble conditions:
TROUBL@SMOKE(PHOTO)@@COMPUTER@ROOM
Z087@MAINTENANCE@REQ@@04:32P@03/01/00@124
Software Zone
The first zone that the
device was mapped to
during programming.
SLC Loop Number
in the range 1-9,
with 0=Loop 10.
Device Address
in the range 01-99.
Device Status
Time and Date
Hour:Minute Month/Day/Year
NOTE
The piezo sounder will sound steadily for unacknowledged trouble conditions.
GN ALARM FORC
GN SUPR FORC
GN TRBL FORC
GN WAT FORC
GN WATER FLW
MON NORM CLD
MON PULL STA
MONITOR
MONITOR PAGE
NON ALARM
NON ALM MON
PAGE
POWER (CONV)
PULL STATION
SMOKE (CONV)
SPEAKER
SPRNKLR MNTR
SPRVSRY MNTR
SYSTEM MONTR
TELEPHONE
TRBL MONITOR
TRBLS PEND
TROUBLE
TROUBLE FORC
WATER FLOW
Detectors:
FIXED PHOT D
FIXED THER D
HEAT(ANALOG)
ION DUCT DET
SMOKE (ION)
SMOKE ION HP
SMOKE ION LP
SMOKE(COMBO)
SMOKE(PHOTO)
Device Type (relates to Software Type ID):
Modules:
ACCESS MONTR
ALARMS PEND
AREA MONITOR
CMX CONTROL
CMX FORM C
CONTROL
DACT CONNECT
EQUIP MONITR
FORMC MANUAL
FORM C RELAY
GENERAL PEND
GN ALARM
GN ALARM EVC
Section Five
Troubles
Custom Device Label
that was entered during
programming.
Type of Trouble:
For Detectors: For Modules:
DET FAILED TEST DEVICE DISABLED SECURITY NO COM
DEVICE DISABLED INVALID REPLY SECURITY TAMPER
DRIFT TOLERANCE OPEN CIRCUIT SHORT CIRCUIT
INVALID REPLY POINT TROUBLE SPRNKLR TROUBLE
LOW CHAMBER VAL SECURITY ALARM SUPRVSRY SIGNAL
MAINTENANCE REQ SECURITY ALERT
PRE-ALARM ALERT
VER COUNT OVFLW
