3-64
Programming 15088:J 10/22/99
Stop Time
(optional)
Start Time
(optional)
Activation Date
(optional)
Activation Day
(optional)
Start Time
(optional)
Stop Time
(optional)
TIM
Operator:Operator:
Operator:Operator:
Operator: The
TIMTIM
TIMTIM
TIM operator is used to specify activation on specific days of the week or year.
Equation:Equation:
Equation:Equation:
Equation:
TIM(SU MO TU WE TR FR SA HH.MM HH.MM)TIM(SU MO TU WE TR FR SA HH.MM HH.MM)
TIM(SU MO TU WE TR FR SA HH.MM HH.MM)TIM(SU MO TU WE TR FR SA HH.MM HH.MM)
TIM(SU MO TU WE TR FR SA HH.MM HH.MM)
(Type 1)
Example:Example:
Example:Example:
Example:
If Z221 CBE is: TIM(SA SU 7.30 13.59)If Z221 CBE is: TIM(SA SU 7.30 13.59)
If Z221 CBE is: TIM(SA SU 7.30 13.59)If Z221 CBE is: TIM(SA SU 7.30 13.59)
If Z221 CBE is: TIM(SA SU 7.30 13.59)
Zone Z221 will be active on Saturdays and Sundays from 7:30AM to 1:59PM.
Equation:Equation:
Equation:Equation:
Equation:
TIM(MM-DD-YY HH.MM HH.MM)TIM(MM-DD-YY HH.MM HH.MM)
TIM(MM-DD-YY HH.MM HH.MM)TIM(MM-DD-YY HH.MM HH.MM)
TIM(MM-DD-YY HH.MM HH.MM)
(Type 2)
Examples:Examples:
Examples:Examples:
Examples:
If Z222 CBE is: TIM(7-4-)If Z222 CBE is: TIM(7-4-)
If Z222 CBE is: TIM(7-4-)If Z222 CBE is: TIM(7-4-)
If Z222 CBE is: TIM(7-4-)
` Zone Z222 will be active on July 4th for every year.
If Z222 CBE is: TIM(12-25- 9.00 17.00)If Z222 CBE is: TIM(12-25- 9.00 17.00)
If Z222 CBE is: TIM(12-25- 9.00 17.00)If Z222 CBE is: TIM(12-25- 9.00 17.00)
If Z222 CBE is: TIM(12-25- 9.00 17.00)
` Zone Z222 will be active on December 25th for every year from 9:00AM to 5:00PM.
SDEL
Operator: The SDEL operator is also used for delayed operation. This is a latched version of the DEL
operator. Once the equation evaluates True, it remains activated until a reset, even if the in-
ternal equation becomes false.
Equation: SDEL(HH.MM.SS HH.MM.SS (Z1))
Example: If Z223 CBE is: SDEL(00.00.30 00.01.30 (L1M1))
IF L1M1 has been active for 30 seconds
THEN Z223 will become active. Z223 will stay active for 1 minute and 30 seconds.
Time line
0:00 0:30 1:00 1:30 2:00 2:30
+————+————+————+————+————+
L1M1 Z223 Z223
active active inactive
NOTES
• The entire SDEL equation consumes at least 11 bytes (including a 3-byte Internal Equation). The
Internal Equation can be a complex equation many bytes in size.
• If a delay of zero is entered (00.00.00), the equation will evaluate true as soon as the Internal Equation
evaluates True and will remain that way for the specified duration.
• If no duration is specified, then the device will not deactivate until reset.
Delay
Duration
(optional)
Internal
Equation
