NV-E6GCP1” OLEDControlPad
1. Thisindicatesthecurrentaudiosourceplayinginthatzone.Sourcenamescanbecustomizedinthe
ConfiguratorSoftwarewithathree-characterdesignation.
2. EachControlPadcomeswithwhite,ivory,almond,andblacktrimplatesthatofferascrewlessandelegant
finishedinstallation.
3. Theorganiclightemittingdiodedisplayisahighlyfunctionalandvividmulti-linedisplay.
4. Thisportionofthedisplayservestwofunctions:Innormaloperation,itindicatestheartist,
station,metadata,andothersourceinformation,andinMenumode,itdisplaysmultiplelinesofinformationforbrowsing
purposes.
5. ThisbargraphindicatestheaudiovolumelevelwhentheControlPadisinnormalplaymode.
WheninMenuMode,itindicatestheplaybackstatusofdigitalmusicfilesfromtheMusicPortorNuVoDockforiPod.
6. Thisbuttonturnsthelocalzoneonandoffandhastheabilitytoturnallzonesoffsimultaneously.
7. Menuservesasaccesstomusicbrowsing,presets,andfavorites,aswellasspecificzoneandsystemsetting
parameters.
8. ThisIRprogrammablebuttontogglesbetweentheplayandpausefunctionsofthechosensource.Whenusing
theT2Tuners,thisbuttontogglesthroughtheTuner'sreceivemodes.Athird “pressandhold” functioncanalsobeassigned
tothisbuttonforadditionalfunctionality.
9. TheOKbuttonservesadualfunction.Innormalplaymode,itscrollsthroughtheavailableaudiosources.InMenumode,it
isusedtoselectthehighlightedmenuitem.
10. ThisisanIRprogrammablebuttonforsimplesourcetransportfunctions.Typically,itwouldtrackforward
andbackortuneupanddown.Athird “pressandhold” functioncanalsobeassignedtothisbuttonforadditional
functionality.
11. Thesearrowshaveadualfunction.Innormalplaymode,theycontrolthevolumelevelupanddown.In
Menumode,theyscrollupanddownthroughmenuselections.
12. TheControlPadhasabuilt-inIRreceiverforcompletewirelesscontrolofallaudiosourceequipment.
SourceIndicator:
WallPlate:
OLEDDisplay:
NowPlaying/MenuDisplay:
VolumeLevelIndicator:
Power:
Menu:
Play/Pause:
OK:
Forward/Reverse:
ArrowUpandDown:
IRReceiver:
