VII.ConnectingtheIREmittersforThird-PartySource
Components(Fig.6)
IRcommandsforthesourceequipmentaretransferredfrom
theGrandConcertoamplifiertothesourceequipmentusing
theminiIRmouseemitters.Sixofthesearesuppliedwith
theGrandConcertoSystem.Theemitterispluggedintothe
correspondingsourceIRoutputontheGrandConcertoand
thenplacedovertheIRreceiverwindowonthesource
component.TheIRoutputsareindividuallyroutedto
sources1-6.
NuVoT2GTunerDirectNumericAccess(Fig.7)
TheNuVoT2GTunershavetheabilityfordirectIRaccessto
numericstationtuning.ThiscanbedonethroughtheT2G
remotecontrolorusingathirdpartyremotecontrolthathas
beentaughttheT2GIRcodes.Toallowthiscontrol,itis
necessarytolinkoneoftheGrandConcertoSUMIRoutputs
totheDirectIRinputontheT2Gusingastereo3.5mm
(1/8”)monopatchcable.Oncetheconnectionismade,the
T2GwillrespondtothenumericIRcommandsissued
throughtheGrandConcertoControlPadIRreceivers.
Fig.6
Fig.7
NuVoDockforiPod
NotethatalthoughtheNuVoDocksystemhasa16position
rotaryswitchforsourceinput,onlypositions1-6areused.
BoththewiredandwirelessNuVoDocksforiPoduseasimple
rotaryswitchtosettheappropriatesourceinput.Uptotwo
wirelessNuVoDocksand6wiredNuVoDockscanbeusedas
individualsourcesthroughNuVoNet.Thewiredandwireless
NuVoDocksconsistofthedockforiPodplaybackand
rechargingandareceivercomponentdesignedto
communicatewithNuVoNet.Priortopluggingthereceiver
intotheGrandConcertoEZPort,settheSourcerotaryswitch
tothedesiredsourcenumberinput.Onceset,theGrand
ConcertoControlPadswillautomaticallydisplaytheiPod
informationwhenaniPodispluggedintotheNuVoDock.
EachNuVoDockandreceivermusthaveaseparatesource
numberselected.
303 3118
I
N
T
E
R
T
E
K
CM
ModelN V-T 2S IR
Dua lSIRIU SReady A M/F MTune r
www .nu vo tec hno logie s.com
NuVoTechnol og iesL LC He br on ,KY US A•
CONF ORMSTOU L
STD. 60065C ERTIF IED
TOCAN /CSA STD .
C22. 2No.60 065:0 6
RS232
SYST EM
NuVoNe t
IRINPUT
RoHS
SYST EM
ZONET RIGGEROU TPUTS
EMIT TEROUTPU TS
SYSON
EXT.MUTE
SUM1
1 3
5
7
8
1
3 5
2
4
6
SUM2
2 4
6
6
T2TunerIRInput
GrandConcertoIROuput
MusicPortMPS4andMPS4-E
TheMusicPortandMusicPortElitesourcecomponentsuse
theIPconnectiontothehome’snetworkrouterforthe
sourceaddressselection.TheMusicPortRemoteConfig
utilityisaccessedthroughaninternetbrowserbyentering
theMusicPort’sIPaddressfollowedby/config,ie.
192.168.1.189/config.TheRemoteConfigwillopenanda
“SourceAddress” taballowsyoutosetthesourcenumber
foreachofthefourMusicPortaudiooutputs.These
selectionsaresavedtotheMusicPort’sflashmemoryand
whenitsNuVoNetoutputisconnectedtotheEZPort,the
attachedGrandConcertoSystemwillrecognizetheMusic
Portsources.
TheSUM1andSUM2outputswillflashanyIRcommandthat
issentfromanyofthezones.Thisismostcommonlyused
withanIRblasterdesignedtoflashIRcommandstoavariety
ofcomponents.
