Print Controller User’s Guide 1-5
Chapter 1 Overview
● Hardware Configuration
Basic Configuration
Configuration of the print controller is as follows:
●
Architecture: IBM Compatible PC System
●
Processor: Intel Celeron 800 MHz
●
Memory: 64 MB standard / 256 MB max. (option)
●
Hard Drive: IDE compatible 2.0 GB min.
●
Floppy Drive: 3.5" Floppy Disk 1.44 MB
● Interface
Parallel
Centronics (IEEE 1284)
Ethernet (option)
100BaseTX and 10BaseT
The optional network interface card is used to connect to the Ethernet. This card is the
internal network interface card which supports multiple protocols on the Ethernet. This
card includes a CPU and flash memory with an upgradable program.
The network interface card supports the following network protocols.
●
IPX/SPX (NetWare, Peer to Peer)
●
TCP/IP (LPD/LPR, Peer to Peer)
●
AppleTalk (EtherTalk)
Refer to the corresponding operating manual for how to use the network interface card.
Do not use the parallel port with the Ethernet interface. Otherwise, a system
error may occur.
IEEE 1394
The maximum transferring rate is 200 Mbps.
Use the Océ engine interface only to connect the print controller and the main
body printer. Otherwise, a system error may occur.
