Pre-Operating Section
2.1 Instrument and Controls, cont.:
Ignition Switch:
Used to power the accessories and start the unit.
ACCESSORIES - rst position
STARTER ENGAGE - second position (springs return to
rst position)
Strobe Toggle
This switch toggles the strobe light on the Blower Housing
(6.3 & 8.2)
CONTROL MODULE
To enter Menu system
Hold Menu button and press Enter◄ button
Menu Navigation
Press Menu to scroll menu options
Press Up▲ arrow to enter Menu option
Press Down▼ arrow to retun
Exit Menu System
Hold Menu button and press Enter◄ button
To Change A Setting
Press Enter◄ button to bring up brackets [ ]
Press Up▲ arrow button and Down▼ arrow button to
change setting
Press Enter◄ button to make selection, brackets dissapear
*Recycle Key to the OFF position after changing a set-
ting*
Main Menus
>Active Engine Fault Codes
View/Scroll Active Codes
>Stored Engine Fault Codes
View/Scroll Stored Fault Codes
>Engine Parameters
View ECU Engine Information
(%Load, Torque, Oil Temp, ect)
>Engine Identication
Engine Model # View
Engine Seriel # View
>Module Information
Control Unit Part# View
Control Unit Software Version View
>Controller Set
Input Conguration
Throttle Conguration
Module Conguration
CAN Conguration
MOD bus Conguration
