Pre-Operating Section
2.1 Instrument and Controls, cont.:
Conguration Menus (Controller Set)
>Input Conguration
Analog 1 Funtion
Digital 1 Function
>CAN Conguration (Throttle)
Throttle type Selection
TSC Minimim Speed
TSC Maximum Speed
TSC Ramp Rate
Throttle Curve Selection
>Module Conguration
Display Units (English, Metric)
Hourmeter Source (Engine ECU, Internal)
Battery Source (J1939, Internal)
Battery Volt Trim
>CAN bus Conguration
Source Adsress (Default=44) Others Available
TSC1 Address (Default=3) Others Available
Engine Address (Default=0) Others Available
Oil / Fuel Transmit
>MOD bus Conguration
Baud Rate
Parity
Stop Bits
Slave Address
Enable Gauges
Tachometer Range
Engine Oil Tempertature Range
Transmission Oil Temperature Range
To access the controller setup menus (Conguration Menus), a password is required
