42641101TH Rev.1 54 /
Oki Data CONFIDENTIAL
LEDStatus level
Table 5-1 (1/5)
Light
No Light
Varies
Varies
Blink
Varies
Varies
Varies
Blink
Blink
Blink
Blink
Varies
Varies
Varies
or Blink
Normal
Normal
Normal
Normal
Normal
Normal
Normal
Normal
Normal
Normal
Normal
Warn-
ing
Normal
Normal
Warn-
ing
The following are the meaning of the symbols in the LCD display.
“TRAY2” is indicated only when the second tray is set, and “MPF” is displayed only when the
multipurpose feeder is set.
xxxx: Emulation (AUTO, PCL, PSE, PPR, FX)
tttt: Trays (TRAY1, TRAY2, MPF, MANUAL)
mmmm: Paper Size (LETTER, A4 SIZE, ..., B5 SIZE, A6 SIZE)
pppp: Media type (Plain, Transparency, ...)
cccc: COVER (UPPER, TRAY2)
The following are indicated in the contents section of the displayed table.
(Job Account-related): Displayed only when the Job Account function is valid.
(PSE-related): Displayed only when PSE is set.
(PSE stands for Postscript3 Emulation. Only when PSE is set.)
(TRAY2-related): Displayed only when TRAY2 is set.
(RS232C-related): Displayed only when an RS232C card is set.
(NIC items): Displayed only when an NIC card is set.
LCD
ON-LINE
xxxx
OFF-LINE
xxxx
FILE
ACCESS
ARRIVE
xxxx
ACTIVE
xxxx
DATA
xxxx
PRINTING
■
■kkk/lll
FLUSHING
FLUSHING
(JAM)
FLUSHING
(DENIED)
FLUSHING
(LOG)
■
WARM UP
■
PWR SAVE
■
TONERLOW
Descroption
Shows on-line status.
Shows off-line status.
Accessing to an accounting file. (Job Account-related)
Data receiving, process not started yet. Displayed mainly during
PJL process without text print data or during job spooling.
Data receiving output processing
Un-printed data remains in Buffer. Waiting for data to follow.
Printer is printing.
Printing a copy. kkk indicates the number of sheet being printed. lll
indicates the total number of sheets that have been printed.
The display for normal printing is applied when the number of
copies is one sheet. This item is displayed combined with a
different message in the first line.
Job cancellation has been instructed. Data is being ignored till the
end of the job.
Indicates a status of discarding data until the end of a job after a
job is cancelled when a jam is generated upon turning jam recov-
ery OFF. MSG blinks only on the top LCD line.
Cancelled as permission for printing has not been received. (Job
Account-related)
1. MSG blinks only on the top LCD line when a job is received from
a user who has not received permission for printing.
Indicates that a job has been cancelled as the area storing logs
inside the printer has been drained and furthermore, a “cancel job”
instruction appears when logs are full.
(Job Account-related) MSG blinks only on the top LCD line.
Indicates that the printer is now warming up. This item is displayed
combined with a different message in the first line.
A printer is in power save mode. Displayed combined with other
messages in the first line.
Toner amount is low. Displayed combined with other messages in
the first line. Normal operation is possible. Not displayed, when a
drum counter is in 200 or less state or a "CHG DRUM" state.
• In the case of “LOW TNR” of a menu is "STOP", TONER LOW
is usually detected from a state, LED is blinked, and it once
becomes OFF-LINE. It will be in an ON-LINE state by cover
opening and closing under push ON-LINE SW. If blink will be in
an ON-LINE state, it will usually return to a state.
To Next Page
