94 User’s Guide
Options
• SCSI Interface for Macintosh
(Part No. 41065001)
• USB Interface Kit for iMac & Window 95/98
®
(Part No. 41065101 )
• Dye Sublimation Upgrade Kit (enables dye subli-
mation printing capability)
(Part No. 41064901)
DIP switches
DIP switches are used to set the SCSI ID number.
The following summarises the settings for each SCSI
device number.
Note 1:
Factory default setting is No.6.
Note 2:
SCSI device number 7 is reserved for the Macintosh
itself. Device number 0 is normally assigned to the
internal hard disk drive, if there is one. To be safe, use
only device numbers 1 through 6.
1 2 3 4 SCSI No.
OFF OFF OFF OFF No. 0
ON OFF OFF OFF No. 1
OFF ON OFF OFF No. 2
ON ON OFF OFF No. 3
OFF OFF ON OFF No. 4
ON
OFF
12
3
4
ON OFF ON OFF No. 5
OFFONONOFFNo. 6 (note 1)
ON ON ON OFF No. 7 (note 2)
1 2 3 4 SCSI No.
