3. Paper Specifications
3-1. Paper Width
(1) Paper width of 83 mm: 83
0
-1.0
mm; paper width of 80 mm: 80
0
-1.0
mm
(2) Paper width within a range of 70 to 25.4 mm (by units of 1 mm)
: 70 to 25.4
0
-1.0
mm
Note: Paper with a width within a range of 71 to 79 mm cannot be used.
3-2. Paper Thickness
: 75 to 150 µm
3-3. Forms of Paper
(1) Roll paper
- Outside diameter: 102±0.5 mm or less
With the large-diameter roll paper unit (option) attached, the printer can use
a roll with an outside diameter of up to 200 mm.
- Core dimension: Inside diameter of 1 inch
(inside diameter: 25.4±0.5 mm; outside diameter: 32±0.5 mm)
- Printed surface: Outside of the roll
- Treatment of end of paper:The roll paper must not be glued to the core.
The end of the paper must also not be folded back.
Note: Do not use rolls that have rough sides or sides from which pieces of paper
extrude. Using such rolls could cause a printer failure.
