200
13-3. Paper Supply Specifications
(1) Loading method: Rolls are loaded manually.
(2) Paper near end: Detected when only a little paper is left.
(µm)
The outside core diameter <B> of roll paper is 32 mm.
Remaining paper length
(m)
Note: The above values (i.e., sensed diameter, remaining paper length) are
theoretical values. These values vary depending on actual conditions,
including the paper roll condition and paper thickness.
Note: The outside core diameter is assumed to be 32 mm.
If roll paper with an outside core diameter of other than 32 mm is used, the
paper-near-end detection accuracy deteriorates.
Note: If roll paper with an outside core diameter of less than 32 mm is used, a
transport error may occur when the cutter cuts the paper in full cutting
mode and reaches the core.
