TABLE OF CONTENTS
1. Appearance and Names of Components ·········································· 11
Appended goods ·········································································· 12
2. AC Adapter ················································································ 13
2-1. AC adapter ·········································································· 13
3. Paper Specifications ···································································· 14
3-1. Paper Width ········································································· 14
3-2. Paper Thickness ··································································· 14
3-3. Forms of Paper ····································································· 14
3-4. Paper Types ········································································· 16
3-4-1. Requirements for full-sheet label paper ··························· 18
3-4-2. Conditions for using black mark paper ···························· 19
3-4-3. Conditions for using die-cut label paper ··························· 20
3-5. Recommended Thermal Paper ················································· 21
4. Preparations ·············································································· 23
4-1. Connecting Interface Cable ····················································· 23
4-2. Connecting the drawer kick cable ············································ 26
4-3. Connecting the AC Adapter ···················································· 27
4-4. Disconnecting the AC Adapter ················································ 29
4-5. Turning on the Power ···························································· 30
5. Inserting Paper for Printing ·························································· 31
5-1. Opening the Top Cover ·························································· 31
5-2. Setting the Paper Width ························································· 32
5-2-1. Mounting separator A ··················································· 33
5-2-2. Removing separators A and B ········································ 34
5-2-3. Attaching separators A and B ········································ 36
5-3. Loading Paper ······································································ 38
5-3-1. Loading roll paper ························································ 38
5-3-2. Loading fanfold paper ··················································· 40
5-4. Setting the Paper Guide ························································· 43
5-5. Closing the Top Cover ···························································· 44
6. Setting Up the Printer ································································· 45
6-1-1. Paper layout ································································ 48
6-1-2. Custom paper ······························································ 49
6-1-3. Printing from an application ·········································· 53
6-2. Paper information setting using the utility ································ 54
6-2-1. Paper layout ································································ 54
6-2-2. Setting detailed paper layout information ························ 55
6-3. Setting Paper Information Using the Printer ····························· 58
