215

14-8. Setting the Roll Paper

(1) Insert the paper roll to the included paper roll shaft core and set them in the

large diameter paper roll unit.

Note: To load a new roll paper, first remove the tape and the glued portion at the

beginning of the roll.

Note: The printer cannot print on the glued portion of the paper, so remove

about one turn of the roll paper from the beginning. Any adhesive or other

matter remaining from the glue may stick to the thermal head and cause a

problem such as voids on printouts. For this reason, be sure to remove the

glued portion of the paper.

Note: There is a direction of the installation when the paper is installed. Please

install it like the clause 14-8- (3).

Roll paper shaft

Roll paper
