12-4. Specifications of Power Supply
(1) Operating voltage : DC 24V±10%
(2) Current consumption :- Standby: 4.5W or less/0.2A on average
Note: Maximum drawer kick drive current: 1A
Two drawer kicks must not be driven
simultaneously.
- Average current consumption Operating: About
44W/1.5A on average
(at 24V, 25°C, print density setting 100%, paper
width 80mm, print duty 9%)
Arrangement of power connector pins
Note : Use our AC adapter to supply power.
Note : If our AC adapter is not used (power supply is supplied by the user),
problems such as bad print quality, electromagnetic interference, or
circuit noise may occur. In such cases, take note of the following points:
· Use an AC adapter whose capacity corresponds to the printing rate that
will actually be used.
· Ensure in advance that there are no problems such as static electricity,
electromagnetic interference, circuit noise, etc.
