<Drawer connection 2>
Printer
2
3
4
5
6
Cable
2
4
Drawer kick solenoid
(24 Ω minimum)
Drawer open/close
switch
2
4
6
Drawer kick solenoid
(24 Ω minimum)
Drawer open/close
switch
1
3
6
Drawer 1
3
Drawer 2
