Oki MC563 Advanced Manual

- 281 -
9. Operating Management/ Specifications
• Wireless(Infrastructure) Setting (If wireless LAN module fitted)
WINS Server (Primary) 0.0.0.0 Sets the name or the IP address for the
WINS server.
This item is displayed when TCP/IP protocol
is enabled.
WINS Server (Secondary) 0.0.0.0 Sets the name or the IP address for the
WINS server.
This item is displayed when TCP/IP protocol
is enabled.
Proxy Disable Sets whether to use proxy.
Proxy Server (NULL) Sets the name or IP address of the proxy
server. You can enter up to 15 characters.
Proxy Server Port No. 8080 Sets the port number of the proxy server.
Proxy User ID (NULL) Sets the user ID to connect to the proxy
server.
Proxy Password (NULL) Sets the password to connect to the proxy
server.
Web Enable Sets whether to enable access from a Web
browser.
This item is displayed when TCP/IP protocol
is enabled.
Telnet Disable Sets whether to enable access from the
Telnet.
This item is displayed when TCP/IP protocol
is enabled.
FTP Disable Sets whether to enable access with FTP.
This item is displayed when TCP/IP protocol
is enabled.
IPSec Disable This item is displayed only if IPSec is set to
valid. This item can be changed to disable
only.
This setting can be enabled only on the web
page.
SNMP Enable Sets whether to enable access from SNMP.
This item is displayed when NetWare or TCP/
IP protocol is enabled.
Network Scale Normal [Normal]: The machine operates effectively
even if connected to a HUB with the
spanning tree function. However, the
machine takes longer to start up if it is
connected to a small LAN that consists of two
or three computers.
[Small]: This setting covers a small LAN that
consists of two or three computers to a large
LAN, but the machine may not operate
efficiently if it is connected to a HUB with the
spanning tree function.
Item Factory default setting Description
Gigabit Network Disable Sets whether to enable access with Gigabit
Ethernet.
HUB Link Setting Auto Sets the hub linking method. Normally, select
[Auto Negotiate].
Item Factory
default
setting
Description
Wireless(Infrastructure) Disable Sets whether to enable
Wireless(Infrastructure).
Network Setting IP Address Set Auto Sets the method of assigning an IP address.
IPv4 Address 192.168.101.10
0
Sets an IP address.
This item is displayed when TCP/IP protocol
is enabled.
Subnet Mask 255.255.255.0 Sets a subnet mask.
This item is displayed when TCP/IP protocol
is enabled.
Gateway
Address
0.0.0.0 Sets a gateway address.
This item is displayed when TCP/IP protocol
is enabled.
DHCPv6 Disable Specify whether to enable DHCP when using
IPv6.
Automatic Setup (WPS) WPS-PBC - WPS-PBC is executed.
WPS-PIN - WPS-PIN is executed.
Wireless
Network
Selection
A list of access point name found
in the search
- Displays a list of wireless LAN access points'
names that are found in a search.
Manual Setup SSID (NULL) Enter an SSID.
Security Disable Selects the security of the wireless LAN
function.
[WPA/WPA2-EAP] and [WPA2-EAP] can be
set only on the Web.
WEP Key (NULL) Displays if [Security] is set to [WEP].
Enter the WEP key.
WPA
Encryption
Type
AES Select a WPA2-PSK encryption type.
Displays if [WPA/WPA2-PSK] or [WPA2-PSK]
is selected for [Security].
WPA Pre-
shared Key
(NULL) Enter the Pre-shared Key.
Displays if [WPA/WPA2-PSK] or [WPA2-PSK]
is selected for [Security].
Wireless reconnection - Wireless(Infrastructure) reconnection is
executed.
Item Factory default setting Description
