Oki MICROLINE 8810 User Manual

Microline 8810 User’s Guide
10
8810 FF.jpg
Engages the Quiet
Print mode.
Continuous Forms
• In the print position: form feeds to next
TOF position.
• Loaded on the tractors, but not in the
print position: the paper advances to the
print position.
Single Forms
• If a form is loaded into the printer, it is
ejected.
Menu Mode
• Scrolls forward through available items
within a group.
8810 LF.jpg
Engages the
Normal Print mode.
Advances forms one line at a time. Press
and hold for repetitive line feeds.
Menu Mode
• Scrolls backward through available items
within a group.
8810
Toggles the eject
direction for single
sheets between
the front and back
of the printer.
Continuous Forms
• In the print position: parks the paper
(moves it out of the print path, back to
the tractors).
• Loaded on the tractors, but not in the
print position: the paper advances to the
print position.
Single Forms
• If a form is loaded into the printer, it is
ejected.
• In the Auto Feed mode, with the optional
CSF installed, if no paper is loaded on the
platform, press LOAD to feed a sheet
from the CSF into the print position.
Menu Mode
• Saves any changes made in the menu
and exits the Menu Mode, placing the
printer back on line.
Individual Switches (Continued)
Switch Printer On Line Printer Off Line (Deselected)

Oki MICROLINE 8810 Specifications

General

Color	No
Built-in barcodes	EAN13, PostNet, UPC-A, UPC-E
Maximum number of copies	8 copies
Fonts included	5
Media thickness	0.48 mm
Dimensions (WxDxH)	598 x 397 x 235 mm
Power requirements	120V-240V (±10%, 50Hz/60Hz)
Connectivity technology	Wired
Compatible operating systems	Windows Vista 32/64, XP, 2000, 98, NT 4.0, 2003 Server
Print direction	Bi-directional
Maximum duty cycle	24000 pages per month
Mean time between failures (MTBF)	10000 h
Sound pressure level (printing)	55.5 dB
Power consumption (standby)	25 W
Power consumption (typical)	120 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	30 - 85 %
