Microline 8810 User’s Guide
38
Manual Feed
Note The default setting is in bold blue type.
Item Settings
Line Spacing 6 LPI , 8 LPI
Auto Eject Pos. 3.18 mm (1/8”),
6.35 mm (1/4”)
Page Widt h 8”. 10.6”, 1 3. 2”,
13.6”
8” = 203,20 mm, 10,6” = 269,24 mm, 13,2 = 335,28, 13,6 =
345,44
Page Length 76.2 mm (3"), 82.6 mm (3.25"), 88.9 mm (3.5"),
101.6 mm (4"), 127.0 mm (8"), 139.7 mm (5.5"),
152.4 mm (6"), 177.8 mm (7"), 203.2 mm (8"), 215.9
mm (8.5"),
279.4 mm (11") , 296.3 mm (11.67"),
304.8 mm (12"), 355.6 mm (14"), 431.8 mm (17")
TOF 2.12 mm (1/12”), 3.18 mm (1/8”),
6.35 mm (1/4”) ,
7.62 mm (3/10”), 8.47 mm (1/3”), 10.58 mm (5/12”),
21.59 mm (0.85"), 23.28 mm (11/12”), 25.4 mm (1”),
27.52 mm (13/12”), 1Chr. Set Pos.
Note: 1Chr. Set Pos. automatically appears as the
setting when the front panel has been used to set a
1Chr. Set Pos value for the Manual Feed path. See
page 71.
Wait Time
Auto Alignment
must be disabled to
use Wait Time
.
2.0 sec , 1.5 sec, 1.0 sec, 0.5 sec
Load LF Speed
Fast Speed , Slow Speed
Eject Dir.
Front , Rear
Paper End
On-line , Off-line
Gap Control
Auto , Manual Gap x
x = 1 - 8, A - E. See page 80
Gap Pos.
50.8 mm (2”) , 101.6 mm (4”)
Auto Align (POW) Align 1, Align 2, Align 3, Align 4,
SelectAutoAlign
Auto Align
Align 1 , Align 2, Align 3, Align 4, Invalid

Oki MICROLINE 8810 Specifications

General

Color	No
Built-in barcodes	EAN13, PostNet, UPC-A, UPC-E
Maximum number of copies	8 copies
Fonts included	5
Media thickness	0.48 mm
Dimensions (WxDxH)	598 x 397 x 235 mm
Power requirements	120V-240V (±10%, 50Hz/60Hz)
Connectivity technology	Wired
Compatible operating systems	Windows Vista 32/64, XP, 2000, 98, NT 4.0, 2003 Server
Print direction	Bi-directional
Maximum duty cycle	24000 pages per month
Mean time between failures (MTBF)	10000 h
Sound pressure level (printing)	55.5 dB
Power consumption (standby)	25 W
Power consumption (typical)	120 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	30 - 85 %
