Oki MICROLINE 8810 User Manual

Microline 8810 User’s Guide
12
+
8810 SHIFT.jpg
8810 FF.jpg
Press and hold SHIFT, then press FF repeatedly to
move loaded paper (single sheets or continuous
forms) forward 1/144-inch (0.18 mm) at a time.
If you press and hold SHIFT, then press and hold
LF, the paper will advance in rapid-fire 1/144-inch
(0.18 mm) increments.
+
8810 SHIFT.jpg
8810 LF.jpg
Press and hold SHIFT, then press LF repeatedly to
move loaded paper (single sheets or continuous
forms) backward 1/144-inch (0.18 mm) at a time.
Maximum allowed backward movement is 1/3-inch
(8.5 mm).
If you press and hold SHIFT, then press and hold
LF, the paper will advance backward in rapid-fire
1/144-inch (0.18 mm) increments.
+
8810 LOAD.jpg
8810 SHIFT.jpg
Press and hold both the LOAD and the SHIFT
switches to change the printhead gap setting. The
factory default is Auto Gap in which the required
printhead gap is sensed automatically by the
printer. Use these switches to change the setting to
a manual head gap setting if you are not getting
good print results with AutoGap. See “Gap Control”
on page 57 for more information.
Combined Switches (Continued)
With the Printer Powered Up and Off Line
Switches Task Performed

Oki MICROLINE 8810 Specifications

General

Color	No
Built-in barcodes	EAN13, PostNet, UPC-A, UPC-E
Maximum number of copies	8 copies
Fonts included	5
Media thickness	0.48 mm
Dimensions (WxDxH)	598 x 397 x 235 mm
Power requirements	120V-240V (±10%, 50Hz/60Hz)
Connectivity technology	Wired
Compatible operating systems	Windows Vista 32/64, XP, 2000, 98, NT 4.0, 2003 Server
Print direction	Bi-directional
Maximum duty cycle	24000 pages per month
Mean time between failures (MTBF)	10000 h
Sound pressure level (printing)	55.5 dB
Power consumption (standby)	25 W
Power consumption (typical)	120 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	30 - 85 %
