Oki MICROLINE 8810 User Manual

Microline 8810 User’s Guide
36
Setup
Note The default setting is in bold blue type.
Item Settings
Multi Pass Bi-directional , Uni-directional
Graphics
Bi-directional , Uni-directional
Graphics Data
(ML Only)
8 Bits,
7 Bits
Rcv. Buffer 128 , 0 K
Data Word (ML Only)
8 Bits , 7 Bits
Panel Function
Full , Limited
Path Change
Not Tear Off , Tear Off
CutSheet Smooth
Valid , Invalid
Skp Ovr Binding Invalid,
Valid 1 , Valid 2
High Skip
Yes, No
Eject Condition Bottom Detect , FF Code
Sheet Feed Mode
(Applies only if the optional
CSF is installed.)
Manual , CSF
CSF Select
(Applies only if the optional
CSF is installed.)
CSF Front,
CSF Rear
Print Suppress No , Yes
Auto LF
No , Yes
Auto CR
No , Yes
Print DEL Code
No , Yes
SI Pitch (10) 15 CPI,
17.1 CPI
SI Pitch (12) 12 CPI, 20 CPI
Reset Inhibit No , Yes

Oki MICROLINE 8810 Specifications

General

Color	No
Built-in barcodes	EAN13, PostNet, UPC-A, UPC-E
Maximum number of copies	8 copies
Fonts included	5
Media thickness	0.48 mm
Dimensions (WxDxH)	598 x 397 x 235 mm
Power requirements	120V-240V (±10%, 50Hz/60Hz)
Connectivity technology	Wired
Compatible operating systems	Windows Vista 32/64, XP, 2000, 98, NT 4.0, 2003 Server
Print direction	Bi-directional
Maximum duty cycle	24000 pages per month
Mean time between failures (MTBF)	10000 h
Sound pressure level (printing)	55.5 dB
Power consumption (standby)	25 W
Power consumption (typical)	120 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	30 - 85 %
