Microline 8810 User’s Guide
45
Serial I/F
Note The default setting is in bold blue type.
Note Appears only when the optional RS-232C Serial Interface is installed
Item Settings
Parity
None
, Odd, Even
Serial Data
8Bits
, 7Bits
Protocol
Ready/Busy
, X-ON/X-OFF
Diagnostic Test
No
, Yes
Busy Line
SSD-
, SSD+, DTR, RTS
Baud Rate 300 BPS, 600 BPS, 1200 BPS, 2400 BPS, 4800 BPS,
9600 BPS
, 19200 BPS, 38400 BPS
DSR Signal
Valid
, Invalid
DTR Signal
Power UP
, Select
Busy Time
200mS
, 1 sec
