Microline 8810 User’s Guide
46
Adjustment
Note The default setting is in bold blue type.
Group Item Settings
Adjustment TOF Adj. (Cut) -40 to 0 to +40
in increments of 1/14-inch
TOF Adj.(CSFF)
(Applies only if the
optional CSF is
installed.)
Same as above.
TOF Adj.(CSFR)
(Applies only if the
optional CSF is
installed.)
Same as above.
Front Load Adj. -40 to
0 to +40
in increments of 1/144-inch
Rear Load Adj.
(Applies only if the
optional Rear Push
Tractor is installed.)
Same as above.
PE Adj. (Cut) -15 to
0 to +15
in increments of 1/144-inch
PE Adj. (CSFF)
(Applies only if the
optional CSF is
installed.)
Same as above.
