Oki MICROLINE 8810 - Dot Alignment and Registration

Microline 8810 User’s Guide
47
Adjustment (cont.) PE Adj. (CSFR)
(Applies only if the
optional CSF is
installed.)
Same as above.
PE Adj. (Front) -15 to
0 to +15
in increments of 1/144-inch
PE Adj. (Rear)
(Applies only if the
optional Rear Push
Tractor is installed.)
Same as above.
1stDotAdjCut Left x,
0 , Right y
x = 10 through 1
y = 1 through 10
adjustable in increments of
1/180 inch (0.14 mm)
1stDotAdjAlign Same as above.
1stDotAdjCSFF
(Applies only if the
optional CSF is
installed.)
Same as above.
1stDotAdjCSFR
(Applies only if the
optional CSF is
installed.)
Same as above.
1stDotAdjFront Same as above
1srDotAdjRear
(Applies only if the
optional Rear Push
Tractor is installed.)
Same as above.
Group Item Settings
