(7) Press the [START] button.
 UpdatingstartsandtheprocessingstatusisdisplayedontheLCDscreen.
Status display during update Status display when update is completed
SYSTEMFIRMWARE(OSData)
update in progress
SYSTEMFIRMWARE(OSData) Completed
ENGINEFIRMWARE
update in progress
ENGINEFIRMWARE Completed
SCANNERFIRMWARE
update in progress
SCANNERFIRMWARE Completed
SYSTEMSOFTWARE(HDData)
update in progress
SYSTEMSOFTWARE(HDData) Completed
(8) “UpdatesuccessfullycompletedRestarttheMFP”isdisplayedatthebottomofthe
LCDscreenaftertheupdatingiscompletedproperly.
Firmware Update Mode
System Firmware Version : xxxx(x.x.x.x)
Update Mode : USB Update
Updata Status
* 1. SYSTEM FIRMWARE (OS Data)
* 2. ENGINE FIRMWARE
* PU LOADER FIRMWARE
* PU FIRMWARE
* OPTION TRAY FIRMWARE
* LCF FIRMWARE
* FINISHER FIRMWARE
* DUPLEX FIRMWARE
* 3. SCANNER FIRMWARE
* SU LOADER FIRMWARE
* SU RECOVERY FIRMWARE
* SU FIRMWARE
* 4. SYSTEM SOFTWARE (HD Data)
* FILE SYSTEM SOFTWARE
* APPLICATION SOFTWARE
Completed
Completed
Completed
Completed
Completed
Completed
Completed
Completed
Completed
Completed
Completed
Completed
Completed
Completed
Completed
Update successfully completed
Restart the MFP
Fig.8-7
