20 Control Elements
4.1 Breakdown of the eXp 6000
The key components to the eXp 6000 are shown in figure 4.1.
Via display or video eye glasses you can see the navigation menu and all recorded scans.
All available probes (e.g. Telescopic Probe, Super Sensor, ...) have to be connected via the telescopic
rod assembly.
The control unit is the main processing unit that receives data from the probes (via telescopic rod
assembly), calculates, renders and saves the data.
The external GPS can be used to start GPS navigation without activating the telescopic rod assembly.
The wireless headphones assist you to hear the sound output, that helps to synchronize your walking
procedure.
OKM GmbH
www.okmmetaldetectors.com
Figure 4.1: eXp 6000 with Telescopic Probe and Super Sensor
Wireless
Headphones
Control unit
Probe mount
Telescopic probe
Carrying strap
Telescopic rod
assembly
Video eye glasses
Super Sensor
Probe mount
Display
