Oldham CPS Series User Manual

CPS – User Manual
Page 45
Mot de défaut
D
0
0
0
0
4
3
2
1
Any module fault generates an event, which is identified by a number (hexadecimal coding)
corresponding to the fault type. The number at the end of the second line displays the module error.
The [  ] [  ] keys can be used to change the scroll mode: in normal mode, all events saved
to memory are displayed; in default mode, only the faults saved to memory are displayed.
Fault word
4
3
2
1
1 = Def Flash
1 = Def Temp. Min
1 = Def Zero calibration
1 = Def ROM main memory
2 = Def sensor
2 = Def Temp. Max
2 = Def Sens. calibration
2 = Def RAM
4 = Low line power
4 = Def Meas. Min
4 = Def Zero Sensor
replacement
4 = Def Battery
8 = high line power
8 = Def Meas. Max
8 = Def Sensitivity. Sensor
replacement
8 = module parameter does not
correspond to the module card
Sample fault word: 00A0 = Def Sens. calibration + Déf Sensitivity. Sensor replacement (A = 10 in
hexadecimal = 8 + 2)
Status word
4
3
2 *
1
1 = BitEtatLiss
1 = BitEtatChg
1 = BitEtat0
1 = BitMod0
2 = BitJbFill
2 = BitEtatPar
2 = BitEtat1
2 = BitMod1
4 = BitJbDelay
4 = BitJbWait
4 = BitEtat2
4 = BitMod2
8 = BitEtatCell **
8 = BitJbCar
8 = BitEtat3
8 = BitMod3
**: only for sensor module (indicates presence of a sensor)
2 *
Status
Module Designation
Type
0 ( EtatMes )
Normal measure
1
Sensor CO
0
BitEtat0 ( EtatStab )
Stabilization
2
sensorNO
1
BitEtat1( EtatZInit )
Zero init
3
Sensor NO
2
2
BitEtat0 + BitEtat1
( EtatStab )
Zero Stabilization
4
Sensor EXPLO
3
5
Sensor O
2
4
BitEtat2 ( EtatZVal )
Zero validation
6
Free
5
BitEtat0 + BitEtat2
( EtatSWait )
Sensitivity waiting
7
Free
6
8
Other
7
BitEtat1 + BitEtat2
( EtatSInit )
Sensitivity init
9
4 relay mod
8
10
8 relay module
9
BitEtat0 + BitEtat1 +
BitEtat3 ( EtatSStab)
Sensitivity stabilization
11
Free
A
12
Free
B
BitEtat3 ( EtatSVal )
Sensitivity validation
13
4ana output mod
C
BitEtat0 + BitEtat3
( EtatChg )
Button replace pushed
14
16 log input mod
D
15
Analog input mod
E
16
Free
F
☺

1 E 8000 D 0000 C 0003 I D 0000
01 M 0 T 33°C Cal 300
Status Word
E
8
0
0
0
4
3
2
1
