2KR/2KS
2-3-16
YC3 31 VD B0 P - - Not used
Connected
to the
engine PWB
32 VD C0 P - - Not used
33 VD B0 N - - Not used
34 VD C0 N - - Not used
35 VD B1 P - - Not used
36 VD C1 P - - Not used
37 VD B1 N - - Not used
38 VD C1 N - - Not used
39 VD B2 P - - Not used
40 VD C2 P - - Not used
41 VD B2 N - - Not used
42 VD C2 N - - Not used
43 VD B3 P - - Not used
44 VD C3 P - - Not used
45 VD B3 N - - Not used
46 VD C3 N - - Not used
47 VCLKOUT P O 0/3.3 V DC (pulse) EPWB clock signal
48 GND - - Ground
49 VCLKOUT N O 0/3.3 V DC (pulse) EPWB clock signal
50 GND - - Ground
YC4 1 GND - - Ground
Connected
to the
engine PWB
2 GND - - Ground
3 HSYNCDN P I 0/3.3 V DC (pulse) Image control signal
4 VSYNCD P I 0/3.3 V DC (pulse) Image control signal
5 HSYNCDN N I 0/3.3 V DC (pulse) Image control signal
6 VSYNCD N I 0/3.3 V DC (pulse) Image control signal
7 HSYNCCN P I 0/3.3 V DC (pulse) Image control signal
8 VSYNCC P I 0/3.3 V DC (pulse) Image control signal
9 HSYNCCN N I 0/3.3 V DC (pulse) Image control signal
10 VSYNCC N I 0/3.3 V DC (pulse) Image control signal
11 HSYNCBN P I 0/3.3 V DC (pulse) Image control signal
12 VSYNCB P I 0/3.3 V DC (pulse) Image control signal
13 HSYNCBN N I 0/3.3 V DC (pulse) Image control signal
14 VSYNCB N I 0/3.3 V DC (pulse) Image control signal
15 HSYNCAN P I 0/3.3 V DC (pulse) Image control signal
16 VSYNCA P I 0/3.3 V DC (pulse) Image control signal
17 HSYNCAN N I 0/3.3 V DC (pulse) Image control signal
18 VSYNCA N I 0/3.3 V DC (pulse) Image control signal
19 GND - - Ground
20 GND - - Ground
21 EG_IRN I 0/3.3 V DC EPWB interrupt signal
22 NC - - Not used
23 EG_SO I 0/3.3 V DC (pulse) EPWB serial communication data signal
24 NC - - Not used
Connector Pin No. Signal I/O Voltage Description
Service Manual Y111960-2
