2KR/2KS
2-4-1
2-4 Appendixes
Maintenance parts list
Maintenance part name
Part No.
Alternative part
No.
Name used in service manual Name used in parts list
Paper feed pulley PULLEY,PAPER FEED 906081L -
Separation pulley PULLEY,SEPARATION 906082M -
Forwarding pulley PULLEY FEED A AVGR00660V -
MP paper feed pulley UPPER PULLEY,BYPASS 579812U -
MP separation pulley PULLEY,SEPARATION 906082M -
MP forwarding pulley PULLEY FEED A AVGR00660V -
MP feed roller 1 PARTS ROLLER2 BYPASSFEED SP AVGR12678X -
MP feed roller 2 PARTS ROLLER4 BYPASSFEED SP AVGR12679T -
MP feed pulley RIGHT PULLEY,FEED 579786A -
Left registration roller UPPER ROLLER REGIST AVGR04963T -
Right registration roller RIGHT ROLLER REGIST AVGR04963T -
Feed pulley PULLEY FEED 908160M -
Feed roller 1 PULLEY MIDDLE FEED A AVGR04965L -
Feed roller 1 PULLEY MIDDLE FEED B AVGR04966Y -
Feed roller 2 PARTS ROLLER B FEED SP AVGR12637E -
Feed roller 3 PARTS ROLLER C FEED SP AVGR12638T -
Registration switch SWITCH REGISTRATION AVGR00286D -
Left registration cleaner UNDER CLEANER REGIST 909960Q -
Registration guide GUIDE REGIST F
AVGR02039F -
Rig
ht registration cleaner PARTS,REGISTRATION CLEAN 909949R -
Transfer guide PARTS,GUIDE TRANSFER AVGR07558B -
Laser scanner unit PARTS LSU AVGR12567F -
Slit glass PARTS CONTACT GLASS ADF ASSY AVGR12664V -
Contact glass PARTS CONTACT GLASS (M) ASSY SP AVGR12665Z -
Mirror 1 MIRROR A AVGR03091P -
Mirror 2 and mirror 3 MIRROR B
AVGR03090N -
L
ens - - -
Exposure lamp PARTS LAMP SCANNER AVGR12562A -
Optical rail F - - -
Optical rail R - - -
Original size sensor SENSOR ORIGINAL AVGR00294W -
Transfer roller unit TR-710 AVGR07566K -
Developing unit DV-715 AVGR10133N -
Drum unit DK-716 AVGR07571F -
Main charger unit MC-710
AVGR07574C -
Drum
separation claw PARTS CLAW SEPARATION ASSY AVGR04635S 2GR93190
Fuser unit PARTS FUSER 230 UNIT AVGR12569Y
Heat roller PARTS,ROLLER HEAT SP AVGR04628W
Heat roller separation claw CLAW HEAT ROLLER 908055B -
Press roller PARTS,ROLLER PRESS SP AVGR04629S
Press roller separation claw CLAW PRESS ROLLER AVGR06908F
Y111960-2 Service Manual
