2KR/2KS
2-4-3
Periodic maintenance procedures
Section
Maintenance
part/location
Method
Maintenance
cycle
Points and cautions Page
Test copy
and test
Perform at the maxi-
mum copy size
Test copy Every service
Section
Maintenance
part/location
Method
Maintenance
cycle
Points and cautions Page
Paper feed
section
Paper feed pulley Replace 500K Replace. (Check and clean with
alcohol when user call occurs.)
P.1-5-3
Separation pulley Replace 500K Replace. (Check and clean with
alcohol when user call occurs.)
P.1-5-3
Forwarding pulley Replace 500K Replace. (Check and clean with
alcohol when user call occurs.)
P.1-5-3
MP paper feed pulley Replace 500K Replace. (Check and clean with
alcohol when user call occurs.)
P.1-5-5
MP separation pulley Replace 500K Replace. (Check and clean with
alcohol when user call occurs.)
P.1-5-5
MP forwarding pulley Replace 500K Replace. (Check and clean with
alcohol when user call occurs.)
P.1-5-5
MP feed roller 1 Check or
Clean
Every service Clean with alcohol.
MP feed pulley Check or
Clean
Every service Clean with alcohol.
MP feed roller 2 Check or
Clean
Every service Clean with alcohol.
Left registration roller Check or
Clean
Every service Clean with alcohol.
Right registration roller Check or
Clean
Every service Clean with alcohol.
Feed pulley Check or
Clean
Every service Clean with alcohol.
Feed roller 1 Check or
Clean
Every service Clean with alcohol.
Feed roller 2 Check or
Clean
Every service Clean with alcohol.
Feed roller 3 Check or
Clean
Every service Clean with alcohol.
Registration switch Check or
Clean
Every service Clean with a dry cloth.
Left registration cleaner Replace 500K Replace. (Vacuum when user call
occurs.)
P.1-5-10
Registration guide Replace 500K Replace.
Right registration
cleaner
Replace 500K Replace. (Vacuum when user call
occurs.)
P.1-5-10
Transfer guide Replace 500K Replace. (Check and clean with
alcohol when user call occurs.)
Y111960-2 Service Manual
To Next Page
