Olivetti d-Copia 5200MF User Manual

2KR/2KS
2-4-4
Section
Maintenance
part/location
Method
Maintenance
cycle
Points and cautions Page
Optical
section
Laser scanner unit Check or
clean
User call Clean the shield glass with a dry
cloth.
P.1-5-22
Contact glass Clean Every service Clean with alcohol and then a dry
cloth.
Slit glass Clean Every service Clean with a dry cloth or alcohol (do
not clean with a wet cloth).
Mirror 1 Clean User call Clean with alcohol and then a dry
cloth only if vertical black lines
appear on the copy image.
Mirror 2 and mirror 3 Clean User call Clean with alcohol and then a dry
cloth only if vertical black lines
appear on the copy image.
Lens Clean User call Clean with a dry cloth only if vertical
black lines appear on the copy
image.
Reflector Clean User call Clean with a dry cloth only if vertical
black lines appear on the copy
image.
Exposure lamp Check or
replace
User call Replace if an image problem
occurs.
P.1-5-12
Optical rail Grease User call Check noise and shifting and then
apply scanner rail grease EM-50L.
Original size sensor Check or
clean
User call Clean the sensor emitter and sensor
receiver with alcohol or a dry cloth
only if there is a problem.
Section
Maintenance
part/location
Method
Maintenance
cycle
Points and cautions Page
Transfer/
separation
sections
Transfer roller unit Replace 500K Replace. (Check and replace when
user call occurs.)
P.1-5-29
Section
Maintenance
part/location
Method
Maintenance
cycle
Points and cautions Page
Developing
section
Developing unit Replace 500K Replace. (Check and replace when
user call occurs.)
P.1-5-28
Service Manual Y111960-2
