2KR/2KS
2-4-5
Section
Maintenance
part/location
Method
Maintenance
cycle
Points and cautions Page
Drum
section
Drum unit Replace 500K Replace. (Check and replace when
user call occurs.)
P.1-5-25
Main charger unit Clean User call Clean with a wet cloth and then a
dry cloth.
P.1-5-26
Drum separation claw Check or
replace
User call Replace if the leading edge of the
claws are damaged.
P.1-5-27
Section
Maintenance
part/location
Method
Maintenance
cycle
Points and cautions Page
Fuser
section
Fuser unit Replace 500K Replace. (Check and replace when
user call occurs.)
P.1-5-30
Heat roller Check or
replace
User call Check and replace when user call
occurs.
P.1-5-34
Heat roller separation
claw
Clean 500K Clean with alcohol. (Check and
replace when user call occurs.)
P.1-5-31
Press roller Check or
replace
User call Check and replace when user call
occurs.
P.1-5-32
Press roller separation
claw
Clean 500K Clean with alcohol. (Check and
replace when user call occurs.)
Section
Maintenance
part/location
Method
Maintenance
cycle
Points and cautions Page
Duplex
section
Upper duplex feed roller Clean 500K Clean with alcohol. (Check and
clean with alcohol when user call
occurs.)
Lower duplex feed roller Clean 500K Clean with alcohol. (Check and
clean with alcohol when user call
occurs.)
Duplex feed pulley Clean 500K Clean with alcohol.
Y111960-2 Service Manual
To Next Page
