2KR/2KS
1-6-3
1-6-4 Remarks on engine PWB replacement
When replacing the engine PWB, remove the EEPROM (U3) from the engine PWB that has been removed and then reat-
tach it to the new engine PWB.
Figure 1-6-3
EEPROM
(U3)
Engine PWB
Y111960-2 Service Manual
