2KR/2KS
2-3-25
YC6 1 DPCLK O 0/3.3 V DC (pulse) DP clock signal
Connected
to the DP
2 DPSDO I 0/3.3 V DC (pulse) Serial communication data signal
3 DPSDI O 0/3.3 V DC (pulse) Serial communication data signal
4 DPSEL O 0/3.3 V DC DP select signal
5 DPEND I 0/3.3 V DC DP end signal
6 DPRDY I 0/3.3 V DC DP ready signal
7 DPTMG I 0/3.3 V DC DP timing signal
8 DP CO I 0/3.3 V DC DP open signal
9 NC - - Not used
10 NC - - Not used
11 GND - - Ground
12 GND - - Ground
13 GND - - Ground
14 GND - - Ground
YC7 1 SMOT BN O 0/24 V DC (pulse) SM drive control signal
Connected
to the scan-
ner motor
2 SMOT AN O 0/24 V DC (pulse) SM drive control signal
3 SMOT BP O 0/24 V DC (pulse) SM drive control signal
4 SMOT AP O 0/24 V DC (pulse) SM drive control signal
YC8 1 SGND - - Ground
Connected
to the home
position
switch
2 HPSW I 0/3.3 V DC HPSW: On/Off
3 +5V O 5 V DC 5 V DC power output to HPSW
Connector Pin No. Signal I/O Voltage Description
Y111960-2 Service Manual
