Olivetti d-Copia 5200MF User Manual

2KR/2KS
2-3-27
Connector Pin No. Signal I/O Voltage Description
YC1 1 TOP Y+ I Analog Touch panel Y+ position signal
Connected
to the touch
panel
2 LEFT X+ I Analog Touch panel X+ position signal
3 BOT Y- I Analog Touch panel Y- position signal
4 RIGHT X- I Analog Touch panel X- position signal
YC2 1 SGND - - Ground
Connected
to the LCD
2 SGND - - Ground
3 B5(MSB) O 0/3.3 V DC LCD control signal
4 B4 O 0/3.3 V DC LCD control signal
5 B3 O 0/3.3 V DC LCD control signal
6 SGND - - Ground
7 B2 O 0/3.3 V DC LCD control signal
8 B1 O 0/3.3 V DC LCD control signal
9 B0(LSB) O 0/3.3 V DC LCD control signal
10 SGND - - Ground
11 G5(MSB) O 0/3.3 V DC LCD control signal
12 G4 O 0/3.3 V DC LCD control signal
13 G3 O 0/3.3 V DC LCD control signal
14 SGND - - Ground
15 G2 O 0/3.3 V DC LCD control signal
16 G1 O 0/3.3 V DC LCD control signal
17 G0(LSB) O 0/3.3 V DC LCD control signal
18 SGND - - Ground
19 R5(MSB) O 0/3.3 V DC LCD control signal
20 R4 O 0/3.3 V DC LCD control signal
21 R3 O 0/3.3 V DC LCD control signal
22 SGND - - Ground
23 R2 O 0/3.3 V DC LCD control signal
24 R1 O 0/3.3 V DC LCD control signal
25 R0(LSB) O 0/3.3 V DC LCD control signal
26 SGND - - Ground
27 DE O 0/3.3 V DC LCD control signal
28 SGND - - Ground
29 L_R O 0/3.3 V DC LCD control signal
30 U_D O 0/3.3 V DC LCD control signal
31 SGND - - Ground
32 DCLK O 0/3.3 V DC (pulse) LCD clock signal
33 NC - - Not used
34 SGND - - Ground
35 +5V O 5 V DC 5 V DC power output to LCD
36 +5V O 5 V DC 5 V DC power output to LCD
37 +5V O 5 V DC 5 V DC power output to LCD
38 +5V O 5 V DC 5 V DC power output to LCD
39 SGND - - Ground
40 SGND - - Ground
Y111960-2 Service Manual
