Olivetti d-COPIA5514MF - Connectors;Interior

2-4
Installing and Setting up the Machine > Part Names
Connectors/Interior
1 USB Interface Connector
2 Network Interface Connector
3 Option Interface Slot
4 TEL Connector
5 LINE Connector
6 Fuser Cover
7 Paper Width Guides
8 Tray Extension
9 Multi Purpose Tray
10 Paper Length Guide
11 Paper Width Guides
12 Bottom Plate
13 Size Dial
14 Duplex Cover
