95
BX53M
a
1
4
The stage holder mounting position can be lowered by removing the
stopper of the stage holder.
Remove the stopper of the stage holder before attaching
the stage and the condenser.
Turn the coarse focusing knob to lower the stage holder
a
sufficiently.
1
Removing the stopper of the stage holder
While holding the stage holder, loosen the clamping screw of the
stage holder.
2
Remove the stage holder.
3
Loosen the screw
b
of the stopper to remove it. Retain the removed
screw not to lose it.
Attach the stage holder and tighten the clamping screw at the arbitrary
height.
4
5
b
