DMTA‐10007‐01EN[U8778365],Rev. B,June2010
4LabelsandSymbols
DonottouchtheinnerconductoroftheBNC(orLEMO)connectorstoavoidrisksof
anelectricshock.Upto400 Vcanbepresentontheinnerconductor.Thewarning
symbolbetweentheTransmit/Receive(
T/R)andtheReceive(R)BNCconnectors
showninthefigurebelowindicatesthiselectricshockrisk.
Warning symbol
BNC connector inner conductor
(LEMO 01 series also available)
