DMTA‐10007‐01EN[U8778365],Rev. B,June2010
InstrumentOverview19
5. Ensurethatthegasketofthebatterycompartmentcoveriscleanandingood
condition.
6. Installthebatterycompartmentcoveratthebackoftheinstrument,andthen
tightenthetwothumbscrewstocompletetheinstallation(seeFigure 1‐7on
page 19).
Figure 1‐7Removingthelithium‐ionbattery
1.4.2 AC Charger/Adaptor
TheEPOCH 600ACcharger/adaptorisprovidedwitheveryinstrument.This
charger/adaptorallowsyoutopowertheEPOCH 600withorwithoutabattery
installed,aswellastochargethelithium‐ionrechargeablebatterywheninstalledin
theinstrument.Apowerindicatoronthefrontpaneloftheunitdisplaysthecurrent

statusoftheACcharger/adaptor.
To connect the AC charger/adaptor
1. Connectthepowercordtothecharger/adaptorunitandtoanappropriatepower
outlet.
Battery
compartment
cover
Thumb screws
(2)
Battery
Pipe stand
