BasicOperation43
2.4.2 Angle Beam Calibration
Anglebeamcalibrationstypicallyrequirefoursteps.Eachstepisoutlinedbelow:
To perform angle beam calibration
1. VerifytheBeamIndexPoint(B.I.P.).
2. Verifytherefractedangleofwedge.
3. Completethedistancecalibrationusingstepsofsection2.4.1onpage 39
(CalibrationmodesettoSoundPathorDepthdependingonthereflectortype).
4. Setthesensitivitybycapturingsensitivityholeornotchingate 1,bringingthe
indicationto80 %screen
heightusing(AUTOXX%),andthensettingthe
referencegainbypressing[2
ND F],(REFdB)[seeFigure 2‐18onpage 43].
Figure 2‐18Referencegainsetting
2.5 Data Logger
TheEPOCH 600featuresanonboarddataloggingsystemthatallowsstandard
storageofinspecti on files(Inc)anddedicatedcalibrationfiles(Cal),aswellas
optionalinspectionfilesincorrosionstyleconfigurations(2D,3D,Boiler,etc).
Regardlessoffiletype,eachdiscretedatapointsavedontheEPOCH 600storesall
