TheDCpower,theReceiveprobeconnector,andtheTransmit/Receiveprobe
connectorarelocatedonthetopendoftheEPOCH 600(seeFigure 1‐3onpage 16).
Figure 1‐3Thetopendconnectors
TheUSBOn‐The‐GoportandtheexternalMicroSDmemorycardslotarelocatedon
therightsideof
theinstrument,hiddenbehindthesidedoor(seeFigure 1‐4on
page 17).
DC power connector
Transmit/Receive
transducer connector
Receive transducer
connector
