DMTA‐10007‐01EN[U8778365],Rev. B,June2010

32Chapter2

Whenthe[RANGE],(DELAY),[dB],or(REFdB)direct‐accesskeysarepressed,

commonpresetvaluesappearabovethe[P<n>]parameterkeys.Toselectapreset

value,pressthecorresponding[P<n>]parameterkey.

2.1.5 Special Functions

ThereareseveralspecialfunctionstobeawareofwhileusingtheEPOCH 600:

•Afteradjustingaparameterusingdirect‐accesskeys,youcangetbacktothe

previousmenugroupusingthe[ESCAPE]keyorthe[NEXTGROUP]key.

•Pressingthe[ESCAPE]keyfromanymenugroupwillreturntheuserto

theBasic

menu,whichisthedefaultmenuatstart‐up.

•The[LOCK]key(knobconfigurationonly)automaticallylocksadjustmentofall

parameterstopreventanyunwantedparametermodificationsduetoan

accidentalmovementoftheknob(seeFigure 2‐7onpage 32).

Figure 2‐7Adjustmentknobconfiguration—[LOCK]key

•Pressing[2

ND F],(AUTOXX%)activatestheAutoXX%feature,which

automaticallyadjuststhegaininordertosetthegatedechoamplitudetoXX%of

fullscreenheight(thedefaultXXvalueis80 %).(SeeFigure 2 ‐8onpage 33.)

[LOCK] key
