DMTA‐10007‐01EN[U8778365],Rev. B,June2010
BasicOperation35
• Mode:pulsemodesavailable:P/E(pulse‐echo),Dual,andThru(through‐
transmission)
• Pulser:Pulserwaveformsavailable:SpikeorSquare(tunablesquarewave)
• Freq:Pulsefrequency(squarewavepulsewidth)rangesfrom0.1 MHzto
20.00 MHz
TheSpikepulseisequivalenttoa20‐MHzsquarewavepulse.
2.2.4 Receiver
TheEPOCH 600standardreceiverfunctionsareaccessiblebyselectingtheRcvr
menu.Eachindividualreceiverparameter isdisplayedabovetheparameterkey s,and
canbeadjustedbypressingthecorresponding[P<n>]parameterkey.
ThefollowingreceiverparametersareavailableforliveadjustmentsintheRcvr
menu:
• Filter:Receiverfiltersetting

• Rect:Waveformrectification(Full[fullwave],Half+[halfwavepositive],Half–
[halfwavenegative],RF[norectification])
• Reject:Percentreject(from0%to80 %)
Theeightfiltersavailable onthe EPOCH 600allowbroadbandornarrowband
settingstomatchtherequirementsofagivenapplication.Eachisafullydigitalfilter
setwith
thefollowinglow‐passandhigh‐passcutoffs:
• 0.2 MHz–10 MHz
• 2.0 MHz–21.5 MHz
• 8.0 MHz–26.5 MHz
• 0.5 MHz–4.0 MHz
• 0.2 MHz–1.2 MHz
• 1.5 MHz–8.5 MHz
• 5.0 MHz–15 MHz
• DC–10 MHz
