DMTA‐10007‐01EN[U8778365],Rev. B,June2010
20Chapter1
UseonlytheACpowercordsuppliedwiththeEPOCH 600.DonotusethisAC
powercordwithotherproducts.
Figure 1‐8Connectingthecharger/adaptor
2. LifttherubbersealthatcoverstheACadaptorconnectorontopofthe
EPOCH 600instrument.
3. ConnecttheDCoutputpowercablefromtheACcharger/adaptortotheadaptor
connector(seeFigure 1‐9onpage 21).
To power outlet
DC power plug
EP-MCA-X
AC power cord
