Olympus EPOCH 600 - Figure 1-10 Removing the Battery Compartment Cover and the Lithium-Ion Battery; Figure 1-11 the Alkaline Battery Holder

DMTA‐10007‐01EN[U8778365],Rev. B,June2010
InstrumentOverview23
Figure 1‐10Removingthebatterycompartmentcoverandthelithium‐ionbattery
4. Install8AAsizealkalinebatteriesintothealkalinebatteryholder.
5. Connectthealkalinebatteryholderconnectorintotheinstrument.
6. Positionthealkalinebatteryholderinthebatterycompartment(seeFigure 1‐11
onpage 23).
Figure 1‐11Thealkalinebatteryholder
Battery
Battery
compartment
cover
Thumb
screws (2)
Battery holder
with alkaline
batteries (8)
Battery holder
connector
