Olympus EPOCH 600 - Figure 1-4 the Connectors Behind the Side Door; Figure 1-5 the Rs232;Alarms and VGA out Connectors

DMTA‐10007‐01EN[U8778365],Rev. B,June2010
InstrumentOverview17
Figure 1‐4Theconnectorsbehindthesidedoor
TheRS232/AlarmsandtheVGAOutconnectorsarelocatedatthebackofthe
instrument,intheuppersecti on(seeFigure 1‐5onpage 17).A rubbercoverprotects
eachconnector.
Figure 1‐5TheRS232/AlarmsandVGAOutconnectors
USB port
MicroSD card slot
Side door
The VGA Out connector
The RS232/Alarms connector
